MDR 26Pin Industrial Camera Link Cable
Applications:
- MDR 26 Pin Camera Link Cable for Industrial Cameras
- Connector A: 1*SCSI MDR-26Pin Pitch=1.27mm Solder Type Connector.
- Connector B: 1*SCSI MDR-26Pin Pitch=1.27mm Solder Type Connector.
- Cable length: 0.5m, 1.0m, 2m, 3m, 5m （Customizable）
- Application: Industrial Camera
Product Detail
Product Tags
| Technical Specifications |
| Warranty Information |
| Part number STC-CLC001
Warranty 3 Years |
| Hardware |
| Cable Jacket Type PVC - Polyvinyl Chloride |
| Performance |
| Type and Rate SCSI MDR |
| Connector(s) |
| Connector A 1 - MDR 26 Pin male with PVC Molding and screws
Connector B 1 - MDR 26 Pin male with PVC Molding and screws |
| Physical Characteristics |
| Cable Length 0.5m, 1.0m, 2m, 3m, 5m (Customizable)
Color Black/Gray Connector Style Straight Product Weight 0.175 kg Wire Gauge UL20276 (28AWG+AL)*11P +24AWG*2C+D*2C+AEB PVC Jacket OD=9.0mm Color: Black |
| Packaging Information |
| Package Quantity 1 Shipping (Package)
Weight 0.18 kg |
| What's in the Box |
| MDR To MDR Cable For Camera Link Industrial Camera, MDR 26 Pin Camera Link Cable for Industrial Cameras. |
| Overview |
| Product Description
Camera Link Machine Vision High Flex Cable Assembly, MDR26 male plug to MDR26 male plug, PoCL Power Over Camera Link.
MDR 26 to MDR 26 cable assembly is available and in stock for your Machine Vision applications and needs. Camera Link® is a robust communications link using a dedicated cable connection and hardware specification to standardize the connection between cameras and frame grabbers. It defines a complete interface that includes provisions for data transfer, camera timing, serial communications, and real-time signaling to the camera. It is capable of high-speed, fast transfer of large files with no latency issues and is the only real-time Machine Vision Protocol. A one million flex cycle rating is appropriate for moving cameras, continuous motion, robotics applications, and industrial environments.
high bandwidth parallel communication. Camera Link is a well-established and proven industry standard, and since all Camera Link-compliant products are interoperable, users have the flexibility to choose the best product for their needs without worrying about compatibility between different manufacturers. Camera Link has GenICam support for plug-and-play interoperability.
MDR26 to MDR26, SDR26 to SDR26, and MDR26 to SDR26 connector options are all available to meet whatever connector combination your frame grabber and camera require. All connector combinations are also available in high-flex or standard PVC jacket offerings.
ApplicationMachine Vision Systems, including Frame Grabbers and Cameras Quality Control and Automatic Inspection Process Control Systems Medical Devices and Imaging Robot Guidance and Robotics
|
